Table 39: Cool multiplier furnace - 4 ton
Furnace model Indoor coil model Total capacity Sensible capacity kW
TM9Y100C20MP11 XAUD60G 1.00 0.96 0.96
TM9Y120D20MP11 XAFD48F 1.00 0.98 0.96
TM9Y120D20MP11 XAFD60G 1.02 0.99 0.96
TM9Y120D20MP11 XAHD48F 1.00 0.98 0.96
TM9Y120D20MP11 XAHD60G 1.01 0.98 0.97
TM9Y120D20MP11 XAUD60G 1.02 0.99 0.96
Performance data - 5 ton
See the following tables for performance and multiplier data for the RAC13460B21S unit.
Condenser only performance data - 5 ton
Table 40: Condenser only performance data - 5 ton
Saturated suction
at compressor
Outdoor ambient temperature
Temperature Pressure 55°F 65°F 75°F 85°F 95°F 105°F 115°F
(°F) (psig) MBH kW MBH kW MBH kW MBH kW MBH kW MBH kW MBH kW
35 107 59.4 2.71 56.9 3.03 53.9 3.35 50.6 3.70 47.1 4.08 43.4 4.51 39.6 5.03
40 118 65.2 2.73 62.4 3.05 59.1 3.37 55.5 3.71 51.7 4.10 47.8 4.53 43.7 5.05
45 130 71.3 2.75 68.2 3.07 64.6 3.38 60.7 3.73 56.6 4.11 52.3 4.55 47.9 5.07
50 142 77.8 2.76 74.3 3.07 70.3 3.39 66.1 3.73 61.7 4.11 57.1 4.56 52.4 5.08
55 156 84.7 2.76 80.7 3.06 76.4 3.38 71.8 3.72 67.0 4.11 62.1 4.56 57.0 5.09
Condenser only performance data notes
• For outdoor unit (condenser) performance only. Data does not include the effects of air handler
power or heat.
• Performance based on 15°F subcooling and 15°F superheat at the outdoor unit base valves:
a. Increase capacity by 1% for each 2°F increase in subcooling.
b. Decrease capacity by 1% for each 2°F decrease in subcooling.
• Maximum recommended condensing temperature is 140°F.
Cooling performance data - 5 ton
Table 41: Cooling performance data - 5 ton - indoor coil: XAFC60GXXN1
IDCFM 1525 1725 1925
ID DB
(°F)
80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
Air
temperature
entering
outdoor unit
(°F)
ID WB
(°F)
57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
T.C. 53.3 56.5 55.7 59.9 61.9 54.8 57.6 56.6 61.0 62.6 56.3 58.7 57.5 62.1 63.4
S.C. 52.6 46.6 39.6 39.1 31.2 54.1 49.2 41.4 41.1 32.4 55.6 51.7 43.1 43.0 33.7
55
kW 3.36 3.39 3.39 3.38 3.41 3.46 3.47 3.48 3.48 3.51 3.56 3.56 3.57 3.57 3.61
T.C. 51.7 55.0 55.0 59.2 62.3 53.4 56.2 56.1 60.3 63.0 55.1 57.4 57.2 61.4 63.6
S.C. 51.0 46.3 39.5 39.2 31.2 52.7 49.1 41.7 41.3 32.5 54.4 51.9 43.8 43.4 33.9
65
kW 3.71 3.73 3.73 3.73 3.76 3.80 3.83 3.83 3.83 3.86 3.90 3.92 3.93 3.93 3.96
T.C. 50.1 53.6 54.3 58.5 62.7 52.0 54.9 55.6 59.7 63.3 54.0 56.2 56.9 60.8 63.9
S.C. 49.4 46.1 39.4 39.2 31.2 51.3 49.0 41.9 41.5 32.6 53.3 52.0 44.4 43.9 34.0
75
kW 4.05 4.08 4.08 4.09 4.11 4.14 4.18 4.18 4.19 4.22 4.24 4.28 4.28 4.29 4.32
Technical Guide: RAC Series RAC134 Models - 13.4 SEER2 Split-System Air Conditioner - Single-Phase86
