Table 7: Furnace capacity - 1.5 ton
Outdoor unit model Furnace model Furnace width
(in.)
Indoor coil
model
Rated CFM Net cool
(MBH)
Sens cool
(MBH)
SEER2 EER2
RAC13418B21S TM8Y060A12MP11 14.5 XAFA18A 625 18.00 13.20 14.00 11.75
RAC13418B21S TM8Y060A12MP11 14.5 XAFA24B 625 18.00 13.20 14.00 11.75
RAC13418B21S TM8Y060A12MP11 17.5 XAFB18A 625 17.90 13.10 14.25 12.00
RAC13418B21S TM8Y060A12MP11 17.5 XAFB24B 650 18.00 13.40 14.75 12.25
RAC13418B21S TM8Y060A12MP11 14.5 XAHA18A 625 18.00 13.20 14.00 11.75
RAC13418B21S TM8Y060A12MP11 14.5 XAHA24B 550 18.00 12.70 14.50 12.25
RAC13418B21S TM8Y060A12MP11 17.5 XAHB24B 625 17.90 13.20 14.00 11.75
RAC13418B21S TM8Y060A12MP11 14.5 XAUA18A 625 18.00 13.20 14.00 11.75
RAC13418B21S TM8Y060A12MP11 14.5 XAUA24B 625 18.00 13.20 14.00 11.75
RAC13418B21S TM8Y080B12MP11 17.5 XAFB18A 650 18.00 13.30 14.50 12.25
RAC13418B21S TM8Y080B12MP11 17.5 XAFB24B 650 18.00 13.40 14.50 12.25
RAC13418B21S TM8Y080B12MP11 17.5 XAHB24B 650 18.00 13.40 14.50 12.25
RAC13418B21S TM9Y060B12MP11 17.5 XAFB18A 725 18.00 13.90 14.00 12.00
RAC13418B21S TM9Y060B12MP11 17.5 XAFB24B 500 17.90 12.30 14.25 12.00
RAC13418B21S TM9Y080B12MP11 17.5 XAFB18A 525 17.70 12.30 14.25 12.00
RAC13418B21S TM9Y080B12MP11 17.5 XAHB24B 500 17.80 12.20 14.25 12.00
Furnace capacity - 2 ton
Table 8: Furnace capacity - 2 ton
Outdoor unit model Furnace model Furnace width
(in.)
Indoor coil
model
Rated CFM Net cool
(MBH)
Sens cool
(MBH)
SEER2 EER2
RAC13424B21S RGF19026AE08MP13 14.5 XAFA24B 750 24.00 17.30 13.75 11.75
RAC13424B21S RGF19026AE08MP13 17.5 XAFB24B 750 23.80 17.10 13.75 11.75
RAC13424B21S RGF19026AE08MP13 17.5 XAFB30C 775 23.80 17.60 14.25 12.20
RAC13424B21S RGF19026AE08MP13 14.5 XAHA24B 725 24.00 17.20 13.75 11.75
RAC13424B21S RGF19026AE08MP13 17.5 XAHB24B 750 23.80 17.10 13.75 11.75
RAC13424B21S RGF19026AE08MP13 17.5 XAHB30C 750 23.80 17.50 14.00 12.20
RAC13424B21S RGF19026AE08MP13 14.5 XAUA24B 750 24.00 17.30 13.75 11.75
RAC13424B21S RGF19026AE08MP13 17.5 XAUB30C 775 23.80 17.60 14.25 12.20
RAC13424B21S RGF19040AE10MP13 14.5 XAFA24B 675 24.00 16.70 14.00 12.20
RAC13424B21S RGF19040AE10MP13 17.5 XAFB24B 700 23.80 16.70 14.25 12.20
RAC13424B21S RGF19040AE10MP13 17.5 XAFB30C 700 23.80 17.00 14.00 12.00
RAC13424B21S RGF19040AE10MP13 14.5 XAHA24B 675 24.00 16.70 14.00 12.20
RAC13424B21S RGF19040AE10MP13 17.5 XAHB24B 700 23.80 16.70 14.00 12.20
RAC13424B21S RGF19040AE10MP13 17.5 XAHB30C 700 23.80 17.00 14.00 12.00
RAC13424B21S RGF19040AE10MP13 14.5 XAUA24B 675 24.00 16.70 14.00 12.20
RAC13424B21S RGF19040AE10MP13 17.5 XAUB30C 700 23.80 17.00 14.00 12.00
RAC13424B21S RGF19060AE10MP13 14.5 XAFA24B 675 23.80 16.50 14.00 11.75
RAC13424B21S RGF19060AE10MP13 17.5 XAFB24B 700 23.80 16.70 14.00 11.75
RAC13424B21S RGF19060AE10MP13 17.5 XAFB30C 700 23.80 16.90 14.25 12.00
RAC13424B21S RGF19060AE10MP13 14.5 XAHA24B 675 24.00 16.70 14.25 12.25
RAC13424B21S RGF19060AE10MP13 17.5 XAHB24B 675 23.80 16.50 14.00 11.75
RAC13424B21S RGF19060AE10MP13 17.5 XAHB30C 675 23.80 16.80 14.25 12.00
RAC13424B21S RGF19060AE10MP13 14.5 XAUA24B 675 23.80 16.50 14.00 11.75
RAC13424B21S RGF19060AE10MP13 17.5 XAUB30C 700 23.80 16.90 14.25 12.00
RAC13424B21S RGF19060BE12MP13 17.5 XAFB24B 800 24.00 17.50 14.25 12.20
RAC13424B21S RGF19060BE12MP13 17.5 XAFB30C 825 24.00 18.00 14.25 12.00
RAC13424B21S RGF19060BE12MP13 21.0 XAFC30C 825 24.00 18.00 14.25 12.00
RAC13424B21S RGF19060BE12MP13 17.5 XAHB24B 800 24.00 17.50 14.00 12.20
RAC13424B21S RGF19060BE12MP13 17.5 XAHB30C 800 24.00 17.80 14.00 12.00
RAC13424B21S RGF19060BE12MP13 21.0 XAHC30C 800 24.00 17.80 14.25 12.00
RAC13424B21S RGF19060BE12MP13 17.5 XAUB30C 825 24.00 18.00 14.25 12.00
RAC13424B21S RGF19080BE12MP13 17.5 XAFB24B 600 23.40 15.70 14.00 12.00
RAC13424B21S RGF19080BE12MP13 17.5 XAFB30C 600 23.80 16.10 14.50 12.00
RAC13424B21S RGF19080BE12MP13 21.0 XAFC30C 600 23.80 16.10 14.50 12.00
RAC13424B21S RGF19080BE12MP13 17.5 XAHB24B 775 24.00 17.30 14.00 11.75
RAC13424B21S RGF19080BE12MP13 17.5 XAHB30C 775 24.00 17.60 14.25 12.00
RAC13424B21S RGF19080BE12MP13 21.0 XAHC30C 600 23.80 16.20 14.50 12.00
RAC13424B21S RGF19080BE12MP13 17.5 XAUB30C 600 23.80 16.10 14.50 12.00
RAC13424B21S RGF19080CE16MP13 21.0 XAFC30C 700 24.00 17.00 14.75 12.25
Technical Guide: RAC Series RAC134 Models - 13.4 SEER2 Split-System Air Conditioner - Single-Phase18
