Table 29: SNE2200x network engine
Specification Description
Network and Serial
interfaces
One Ethernet port; 1000/100/10 Mbps; 8-pin RJ45 connector
Two FC ports (RJ12 6-pin port; connects with 1.5 m [4.9 ft] RJ12 field bus cable)
Two optically isolated RS-485 ports; with a removable 4-pin terminal block
Three USB ports (one Micro-B port, and two USB A ports). All support USB 2.0 and Open Host
Controller Interface [Open HCI] specification; Micro-USB port currently inactive
Transmission speeds Ethernet communication: 100 or 10 Mbps
The network engine can reside and interoperate on a 1 Gbps network, but does not itself
transmit at 1 Gbps.
Optically isolated, serial communication (FC Bus): 76,800, 38,400, 19,200, 9600, or 1200 bps
(selectable)
Ambient temperature
conditions
Operating: 0°C to 50°C (32°F to 122°F)
Non-Operating: -40°C to 70°C (-40°F to 158°F)
Ambient humidity
conditions
Storage: 5% to 95% RH, 30°C (86°F) maximum dew point conditions
Operating: 10% to 90% RH, 30°C (86°F) maximum dew point conditions
Housing Black Polycarbonate and Acrylonitrile butadiene styrene (ABS) blend
IP protection class: IP20
UL flammability rating: UL94-5VB
Mounting On flat surface with screws on three mounting clips or a single 35 mm DIN rail
Dimensions (Height x
Width x Depth)
190 mm x 125 mm x 44.5 mm (7.48 in. x 4.92 in. x 1.75 in.)
Weight 0.387 kg (0.852 lbs)
Compliance United States: UL Listed, File E107041, CCN PAZX, UL 916, Energy Management Equipment;
FCC Compliant to CFR47, Part 15, Subpart B, Class A, Conformance to FIPS 140-2 Level 1 and
validated under NIST Certificate #3389.
Canada: UL Listed, File E107041, CCN PAZX7, CAN/CSA C22.2 No. 205, Signal Equipment;
Industry Canada Compliant, ICES-003
Europe: CE Mark – Johnson Controls, Inc. declares that this product is in compliance with the
essential requirements and other relevant provisions of the EMC Directive.
Australia and New Zealand: RCM Mark, Australia/NZ Emissions Compliant
BACnet International: BTL 135-2020 Listed B-BC/B-RTR/B-BBMD, Protocol Revision 18
FIPS 140-2 Level 1: Compliant and certified with Federal Information Processing Standard;
https://csrc.nist.gov/Projects/cryptographic-module-validation-program/Certificate/3389
United Kingdom: Johnson Controls declares that this product is in compliance with
Electromagnetic Compatibility Regulations, The Electrical Equipment (Safety) Regulations, and
Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic Equipment
Regulations.
Table 30: SNE1100x, SNE1050x, and SNE110Lx network engines
Specification Description
Power requirement Dedicated nominal 24 VAC, Class 2 power supply (North America), SELV power supply (Europe),
at 50/60 Hz (20 VAC minimum to 30 VAC maximum)
Alternate: Dedicated nominal 24 VDC, Class II power supply input; North America: ACC-
PWRKIT-1A24; Europe: ACC-PWRKIT-1E24
Power consumption 38 VA maximum
Operating System Wind River
®
Linux LTS 17 (LTS=long-term support)
Processor NXP i.MX6 DualLite processor, dual core Cortex-A9 processor at 1.0 GHz with 512 KB of L2 cache
SNE Installation Guide 25
