Johnson Controls York VERSECON YSWD Series User Manual

103
JOHNSON CONTROLS
FORM 145.05-NOM1 (708)
POINT ID POINT DESCRIPTION
N2
OBJECT
READ
( R )
WRITE
( W )
VALUE
RANGE
(ANALOG
ONLY)
UNIT
(ANALOG
ONLY)
IN-
STANCE
NUMBER
COMMENTS
COMPA
DISCH OUT
DISCHARGE PRESSURE
COMPRESSOR A
AI18 R 0 – 400 PSIG 16104
COMPA SUCT
OUT
SUCTION PRESSURE,
COMPRESSOR A
AI19 R 0 – 150 PSIG 16105
COMPB
DISCH OUT
DISCHARGE PRESSURE
COMPRESSOR B
AI20 R 0 – 400 PSIG 16106
COMPB
SUCT OUT
SUCTION PRESSURE,
COMPRESSOR B
AI21 R 0 – 150 PSIG 16107
COMPC
DISCH OUT
DISCHARGE PRESSURE
COMPRESSOR C
AI22 R 0 – 400 PSIG 16108
COMPC
SUCT OUT
SUCTION PRESSURE,
COMPRESSOR C
AI23 R 0 – 150 PSIG 16109
COMPD
DISCH OUT
DISCHARGE PRESSURE
COMPRESSOR D
AI24 R 0 – 400 PSIG 16110
COMPD
SUCT OUT
SUCTION PRESSURE,
COMPRESSOR D
AI25 R 0 – 150 PSIG 16111
FAN BP/EXH
EN
STATUS OF THE
CONSTANT VOLUME FAN
OUTPUT
1 = ON – ACTIVE
0 = OFF – INACTIVE
BO26 R/W - - 11001
FAN VFD EN
BINARY OUTPUT TO
ENERGIZE THE SUPPLY
FAN VFD
1 = ON ACTIVE
0 = OFF – INACTIVE
BO27 R/W - 11002 ONLY WITH VAV OR FLEXSYS
PUMP OUT+
INDICATES THE STATUS
OF THE PUMP OUTPUT
BO28 R/W - - 11003
FAN OUT
STATUS OF THE FAN OUT
DRY CONTACT
1 = ON ACTIVE
0 = OFF – INACTIVE
BO29 R/W - - 11004
BOX OPEN
OUT
OUTPUT SIGNAL TO
OPEN THE VAV BOXES
1 = ACTIVE
0 = INACTIVE
BO30 R/W - - 11005
COMPA EN
STATUS OF THE
BINARY OUTPUT TO
COMP A
1 = ON – ACTIVE
0 = OFF – INACTIVE
BO31 R/W - - 11006
TABLE 18 – N2 POINTS LIST
Continued on next page
6
