FORM 145.05-NOM1 (708)
MODEL #
# EVAP
COIL
ROWS
COMP A COMP B COMP C COMP D
NOM HP
R22
CHARGE
LBS
NOM HP
R22
CHARGE
LBS
NOM HP
R22
CHARGE
LBS
NOM HP
R22
CHARGE
LBS
DVW055 6 20 22 15 19 20 21 15 18.5
DVW060 4 15 16.5 7 13 15 16 7 12.5
DVW060 6 15 19.5 7 16 15 19 7 15.5
DVW060 4 15 16.5 10 14.5 15 16 10 14
DVW060 6 15 19.5 10 18 15 19 10 17.5
DVW060 4 15 16.5 12 15.5 15 16 12 15
DVW060 6 15 19.5 12 19 15 19 12 18.5
DVW060 4 15 16.5 15 17 15 16 15 16.5
DVW060 6 15 16.5 15 23 15 16 15 22.5
DVW060 4 20 19.5 12 15.5 20 18.5 12 15
DVW060 4 20 19.5 15 17 20 18.5 15 16.5
DVW060 6 20 19.5 15 23 20 18.5 15 22.5
DVW072 4 15 16 10 15 15 15.5 10 14
DVW072 6 15 19.5 10 18.5 15 19 10 18
DVW072 4 15 16 12 15.5 15 15.5 12 15
DVW072 6 15 19.5 12 19 15 19 12 18.5
DVW072 4 15 16 15 16.5 15 15.5 15 15.5
DVW072 6 15 16 15 24 15 15.5 15 23
DVW072 4 20 19 12 15.5 20 17.5 12 15
DVW072 6 20 22.5 12 19 20 21.5 12 18.5
DVW072 4 20 19 15 16.5 20 17.5 15 15.5
DVW072 6 20 19 15 24 20 17.5 15 23
DVW072 4 25 20 12 15.5 25 19 12 15
DVW072 6 25 24 12 19 25 22.5 12 18.5
DVW072 4 25 20 15 16.5 25 19 15 15.5
DVW072 6 25 24 15 20 25 22.5 15 19.5
DVW079 4 20 20 15 17.5 20 18.5 15 16.5
DVW079 6 20 24 15 21.5 20 22.5 15 20.5
DVW079 4 25 21 12 16.5 25 19.5 12 15.5
DVW079 4 25 21 15 17.5 25 19.5 15 16.5
DVW079 6 25 25.5 15 21.5 25 23.5 15 20.5
DVW079 4 25 21 20 20.5 25 19.5 20 19
DVW079 6 25 21 20 29 25 19.5 20 27.5
DVW079 4 25 21 25 22 25 19.5 25 20.5
DVW079 6 25 21 25 30.5 25 19.5 25 28.5
DVW090 4 20 21 15 18.5 20 19.5 15 17.5
DVW090 6 20 25.5 15 23 20 24 15 22.5
DVW090 4 25 22.5 12 17.5 25 21 12 16.5
DVW090 4 25 22.5 15 18.5 25 21 15 17.5
DVW090 6 25 27 15 23 25 25.5 15 22.5
DVW090 4 25 22.5 20 22 25 21 20 20.5
DVW090 6 25 22.5 20 31.5 25 21 20 29.5
DVW090 4 25 22.5 25 23.5 25 21 25 21.5
DVW090 6 25 22.5 25 32.5 25 21 25 31
TABLE 7 – REFRIGERANT CHARGE DATA (CONT.)
