72
JOHNSON CONTROLS
FORM 145.05-NOM1 (708)
Continued on next page
TABLE 18 – BACnet MS/TP points (CONT.)
Point ID Point Description
Variable
Type
Read ( R )
Write ( W )
Value
Range
(Analog
Only)
Unit
(Analog
Only)
Instance
Number
Comments
CTDuctHP
Number of Trips Registered for
the Duct High Switch Circuit
(0 to 5)
BAV R 16130
CTSafe
Number of Trips Registered for
the Safe Input Circuit (0 to 5)
BAV R 16132
DFS
Dirty Filter Switch Input:
1 = Dirty – Active
0 = Normal – Inactive
BBI R - - 12007
DFS
Dirty Filter Switch Alarm:
1 = Dirty – Active
0 = Normal – Inactive
BBV R - - 15112
Disch P Max* BAV - - 16012 Not Applicable
Disch P StPt* BAV - - 16014 Not Applicable
Dly Sched
The Status of the Daily
Schedule:
1 = On -Active
0 = Off – Inactive
BBI R - - 869
Dly Sched
Turn the Daily Schedule On
and Off:
1 = On -Active
0 = Off – Inactive
BBI R/W - - 869
DmpPrsMod
Bypass Damper Output Based
on Coil Pressure Drop
BAV R 0 – 100 % 16123 Only with FlexSys
DmpSatMod
Bypass Damper Output Based
on Supply Air Temperature
BAV R 0 – 100 % 16122 Only with FlexSys
Duct Hi Static
Status of the Duct Static High
Limit Switch:
1 = Normal – Active
0 = Fault – Inactive
BBI R - - 12005
Duct Stat 1 Out Duct Static 1 Input BAI R 0 – 2 inc wc 16102
Only with VAV or
FlexSys
Duct Stat 2 Out Duct Static 2 Input BAI R 0 – 2 inc wc 16103
Only with VAV or
FlexSys
DuctHP
High Duct Pressure Alarm:
1 = Fault – Active
0 = No Fault – Inactive
BBV R - - 15101
DuctSP Derived Duct Static Input BAV R 0.0 – 5.0 in of wc 16120
Only with VAV or
FlexSys
DX Temp
Evaporator Coil Leaving
Temperature
BAI R 0 – 120 Deg F 13019 Only with FlexSys
DxPrs
Minimum Allowable Pressure
Drop Across the Evaporator
Coil
BAV R/W 0.2 – 1.0 in of wc 16005 Only with FlexSys
User Interface Control Center
