20
SERVICE SPECIFICATIONS AND SPECIAL TOOLS
STANDARD TORQUE SPECIFICATIONS
STANDARD TORQUE SPECIFICATIONS
Standard Torque Chart
Size In. Lbs. Ft. Lbs. N·m
No. 6 7–10 0.58–0.83 0.8–1.1
No. 8 15–22 1.25–1.83 1.7–2.5
No. 10 24–36 2–3 2.7–4.0
No. 12 36–48 3–4 4.0–5.4
1/4 in. 60–84 5–7 6.7-9.4
5/16 in. 120–144 10–12 13.5–16.2
3/8 in. 216–240 18–20 24.4–27.1
7/16 in. 336–384 28–32 37.9–43.4
IMPORTANT: These values apply only when a specific
torque for a specific fastener is not listed in the appropri-
ate section. When tightening two or more screws on the
same part, DO NOT tighten screws completely, one at a
time.
WARNING
Torque wrench tightening specifications
must be strictly adhered to. Replace any
locking fastener (locknut or patch screw) if
its locking feature becomes weak. Definite
resistance to turning must be felt when
reusing a locking fastener.
If replacement is specified or required
because the locking fastener has become
weak, use only authorized Evinrude/
Johnson Genuine Parts.
