English – 37
Repair instructions
7 Pull belt 3 o the unit belt pulley.
8 Lift o belt 4 over the unit belt pulley and
forwards.
Fit the belt in the reverse order.
6.19 Replacing belt 3, cutting unit
drive
Follow the instructions for "Replacing belt 4, as far
as the cutting unit" up until step 7. Then proceed
according to the following instructions:
1 Remove the rear cover of the front frame.
2 Remove the spring for the belt tensioner for belt 1
(engine belt).
3 Remove the belt tensioner for belt 1.
