9-3
3-3) GPS Navigator
(1) Serial Transmission
Channel Specification Notes
DATA IN/OUT1 RS-422 Input or Output NMAE, IEC, JRC
DATA IN/OUT2 RS-422 Input or Output NMEA, IEC, JRC
DATA IN/OUT3 RS-422 Input or Output NMEA, IEC, JRC
RS-485 RS-485 Input / Output NMEA, IEC
(1-1) NMEA
• Specification: NMEA
• Version: Ver1.5, 2.1, 2.3, 4.0
• Bit rate: 4800, 9600,19200,38400bps
• Data bit: 8bit
• Parity: None
• Start bit: 1bit
• Stop bit: 1bit
• Output sentence :
GGA,RMC,GLL,VTG,GSA,GSV,DTM,GBS,GRS,GST,ZDA,GNS,MSS
*
,ALR
APB,BOD,BWC,BWR,RMB,XTE,ZTG,RTE,WPL,ACK
• Output interval: 1s, 2s, 3s, 4s, 5s, 6s, 7s, 8s, 9s, OFF
* : JLR-7900 only
Note) Some combinations of output sentence, bit rate, and output intervals may not be possible.
(1-2) IEC
• Specification: IEC61162-1 ed.4
(1-3) JRC
• Specification: JRC
• Bit rate: 1200bps
• Data bit: 8bit
• Parity: None
• Start bit: 1bit
• Stop bit: 2bit
(2) Contact signal
Channel I/O Notes
CONTACT OUTPUT 200p/NM, 400p/NM, ALARM, ACK
CONTACT INPUT ACK, Input of external dimmer
To Next Page
