Chapter 5 VARIOUS FUNCTIONS

Reference:

Delete All Lines

To delete the set lines at once, focus on the Line on the MULTI menu and long press the MULTI control.

Displays the delete confirmation screen.

Select YES, the all lines will be deleted at once.

Long press

$OOOLQHVDUHGHOHWHG$UH\RXVXUH"
