Chapter 1 INSTALLATION

1.4 CONNECTING THE INSTALLATION CABLE

 Installation cable

Fig. 1-4-1

When installing the optional "rubber cap", attach it to the A connector side after laying the cable.

Connector maximum diameter㸸33.2±0.8mm

Installation cable diameter㸸14.0s0.5mm
