Chapter 1 INSTALLATION
2
1.2 INSTALLATION OF THE DISPLAY UNIT
1.2.1 SELECTING THE INSTALLATION POSITION
Select the display unit installation position by taking into consideration of the followings.
Ŷ Install the display unit so that the user can easily conduct observations.
Ŷ To reduce affect on the magnetic compass, install the display unit more than 1 meter away from
the compass.
Ŷ Take precautions to prevent water from splashing through the window or door of the bridge onto
the display unit.
Ŷ Install the display unit by considering convenience of maintenance.
Ŷ Install the display unit so that when the user is looking ahead, the lookout view is not obscured.
Ŷ Install the unit away from direct sunlight and heat source.
1.2.2 SELECTION OF DISPLAY MOUNTING
Display is designed to various mounting way for users circumstance.
Mounting way.
z Desktop Installation
z Flush Mounting
Note: JMA-3400 series are not supported to ceiling Installation.
