JRC JMA-3404 - Max Interval; Range Limit

Chapter 8 DETAIL PERFORMANCE
1
5
7
8.2.2 MAX INTERVAL
Set the group of trails. Selected group is displayed in the main menu.
Use Short if you use short radar tracks a lot, such as in the bay.
Use Super Long if you need a long radar track, such as in open sea voyages.
Middle is an intermediate specification between Short and Long. In addition, continuous track can be used
for all set values.
Short: OFF/15sec/30sec/1min/2min/3min/4min/5min/6min/10min/15min/Continuous
Middle: OFF/30sec/1min/2min/3min/4min/5min/6min/10min/15min/30min/Continuous
Long: OFF/1min/2min/3min/4min/5min/6min/10min/15min/30min/1hour/Continuous
Super Long: OFF/30min/1hour/2hour/3hour/4hour/5hour/6hour/10hour/12hour/24hour/Continuous
8.2.3 RANGE LIMIT
Set the range to take over trails.
