Travel Adjust
(Function Mode)
The Travel Adjust feature of the XR-2 allows the maximum
travel of both the steering and throttle servos to be increased
or decreased in each direction to achieve the exact servo
movement needed. The adjustment range is from 0 % to
125%. The travel adjustment is factory set to 100% for both
channels. The travel adjustment value displayed on the
screen depends on the current position of the steering wheel,
trigger, or trim lever to be adjusted. This feature is very use-
ful either to maximize servo travel or to reduce servo over-
travel to eliminate servo binding (servo moves further than
control mechanism allows), without the need for mechanical
linkage adjustment.
The screens below are accessed by turning the wheel to the
desired direction to be adjusted (left or right) or moving the
trigger to the forward or backward (brake) position.
Accessing The Travel Adjust
Function
To access the Travel Adjust feature, follow the step below:
1. Turn on the transmitter power switch
2 Press the MODE key to enter the Function Mode.
3. Press the MODE key until TRV ADJ appears in small let-
ters on the left side of the screen.
4. Press the CHANNEL key to select the desired channel to
be adjusted. Steering = STR (steering right) or STL (steer-
ing left); Throttle = FWD (forward) or BRM (braking or
reverse)
5. Move the steering wheel or trigger in the desired direction
for adjustment (left/right, forward/reverse or brake). Press
the INCREASE or DECREASE key to achieve the desired
amount of travel. Move the wheel/trigger in the opposite
direction to adjust the travel in the opposite direction.
6. Press the MODE key to access the Steering Dual Rate
function.
7. To exit the Function Mode, either turn off the transmitter
power switch or press the MODE and CHANNEL keys at
the same time.
Note: When setting the travel adjust values for the
steering function, it’s suggested that if possible
the maximum travel values be set to an equal
value in both directions to maintain proper steer-
ing control.
MODE
ENTER
CHANNEL
INCREASE
CLEAR
+–
DECREASE
stl
100
fwd
100
TRVADJ.
str
100
TRVADJ.
TRVADJ.
brm
100
TRVADJ.
Indicates steering left
travel adjustment
Indicates current
value
Indicates steering
right travel adjustment
Indicates forward
throttle travel
adjustment
Indicates reverse
(brake) travel
adjustment
Indicates current
value
Indicates current
value
Indicates current
value
Press the MODE key
until TRV ADJ appears
on the screen
Press the CHANNEL
key to select the
channel to be adjusted
(steering or throttle)
Move the wheel/trigger in the desired direction
and press either the INCREASE or DECREASE
keys to achieve the desired travel value
