15
Steering Rate
(Function Mode)
The Steering Rate feature of the XR-2 allows the steering
servo travel to be increased or decreased to the desired
amount required. The values of the Steering Rate function
are a percentage based from the travel adjust value set in the
Travel Adjust section.
Example: Travel adjust value 100%, Steering value 80% —
Maximum steering rate is now reduced to 80% of the maxi-
mum travel value (100%)
The Steering Rate function also works in conjunction with
the Grip Lever B Steering Rate function (page 20) and acts as
the maximum rate available through grip dial B. This feature
allows the steering rate to be increased or decreased directly
from the grip lever B while racing to maximize the steering
rate needed for the particular track conditions.
Accessing the Steering Rate
Function
To access the Steering Rate Function, follow the steps
below:
1. Turn on the transmitter power switch.
2. Press the MODE key to enter the Function Mode.
3. Press the MODE key until D/R STM appears on the
screen.
4. Press the INCREASE or DECREASE keys until the proper
steering rate is achieved.
5. Press the MODE key to access the Sub-Trim function.
6. To exit the Function Mode, either turn off the transmitter
power switch or press the MODE and CHANNEL keys at
the same time.
MODE
ENTER
CHANNEL
INCREASE
CLEAR
+–
DECREASE
stm
100
∞
D/R
Indicates Steering
Rate function
Indicates current
value
Press the INCREASE or DECREASE keys to
achieve the desired steering rate value
JR XR-2 7/15/99 8:35 AM Page 15
