17
Accessing the Servo
Reversing Function
To access the Servo Reversing function, follow the steps
below:
1. Turn the transmitter power switch on.
2. Press the MODE key to access the Function Mode.
3. Press the MODE key until REV.NORM appears in small
letters to the right of the screen.
4. Press the CHANNEL key to select the channel to be
changed (ST = Steering, TH = Throttle).
5. Press the INCREASE or DECREASE keys to move the cur-
sor to the desired direction.
6. To exit the Function Mode, either turn off the transmitter
power switch or press the MODE and CHANNEL keys at
the same time.
Servo Reversing
(Function Mode)
The Servo Reversing feature of the XR-2 is a very convenient
feature when setting up a new model. The purpose of the
servo reversing function is to change the direction of the
servo rotation in relation to the wheel/trigger movement. The
Servo Reversing function is available for both the steering
and throttle channels of the XR-2.
MODE
ENTER
CHANNEL
INCREASE
CLEAR
+–
DECREASE
Indicates current
channel
ST = Steering
TH = Throttle
Cursor indicates
current servo
direction
st
—
REV•NORM
Press the CHANNEL
key to select the
desired channel to be
adjusted
ST = Steering
TH = Throttle
Press the INCREASE or DECREASE keys to
move the cursor to the desired servo direction
JR XR-2 7/15/99 8:35 AM Page 17
