Control Identification and Location
Antenna
Steering wheel
Electronic digital
steering trim lever
Dot Matrix multi-
data LCD display
3 digit name input
Digital voltage
reading
Electronic digital
grip lever A
Electronic digital
grip lever B
Power switch
Charge jack
Mode button
= Enter function
= Clear function
Channel button
Increase button
Decrease button
Electronic digital
throttle trim lever
Throttle trigger
Adjustable
steering tension
Battery cover *
(8 AA batteries required)
*To remove, press down where it says “press” and push the cover in the direction of the arrow.
Remove the battery case and install eight AA batteries in the direction shown as molded into the
battery case. If transmitter voltage fails to register, check for correct battery installation and voltage.
