18
Accessing the Direct
Trim Mode
The Direct Mode function of the XR-2 is accessible through
the use of the electronic throttle or steering trim levers, as
well as the two electronic grip levers (A&B) located on the
upper portion of the grip handle. This function allows for
quick trim adjustment of these controls, without the need to
access these functions through the four keypad control keys.
To access the Direct Trim Mode function, turn on the trans-
mitter power switch. Next, move the desired trim lever to be
adjusted. The appropriate screen for the selected trim lever
will be displayed. To adjust, simply move the trim lever in
the desired direction until the correct amount of trim is
achieved. Once the desired trim is achieved, the screen will
return to the Normal display screen after approximately five
seconds from the last trim input. If the MODE or CHANNEL
key are pressed any time during the five seconds, the system
will return to the previous screen in use.
stt
0
tht
0
brg
50
TRVADJ.
stg
70
ā
D/R
Steering Trim, page 19
Throttle Trim, page 19
Steering Dual Rate (Grip Lever B), page 20
Brake Travel Adjustment (Grip Lever A), page 21
JR XR-2 7/15/99 8:35 AM Page 18
