Output function list
Function
code
Abbrev
ia-
t
ion
Function item
Remarks
0 noP No funct
ion
(Standard setting)
1 TrM Thread trimming output Output of thread trimming signal
2 W
iP Thread wiper output Output of thread wiper signal
3 TL Thread release output Output of thread release s
ignal
4 FL Presser l
ifter output Output of presser lifting signal
5 bT Reverse feed st
itching output Output of reverse feed stitching signal
6 EbT EBT
cancel monitor output State of one time cancel of reverse feed stitching at end
function is output.
7 SEbT R
everse feed stitching at start/end
cancel monitor output
State of cancel of reverse feed stitching at start/end is
output.
8 AUbT S
ewing start/end cancellation/addi-
tion monitor output
State of cancel or addition of automatic reverse feed
stitching is output.
9 SSTA Sew
ing machine stop state output Sewing machine stop state is output.
10 CooL Needle cooler output Output for needle cooler
11 bUZ Buzzer output
It i
s output when the bobbin counter set value has been
exceeded, an error has occurred or the bobbin thread
remaining amount is detected.
12 LSWo Revolut
ion command output Revolution demanding command state is output.
13 TSWo T
sw command monitor output Thread trimming command status is output.
Input function setting connectors
Output function setting connector
Connector No. Pin No. Display No. Initial value of function setting
CN36 4 i
01 noP (No function setting)
CN54 3 i
02 noP (No function setting)
CN50 1
2 i03 SoFT (Soft-start speed limit input)
CN36 5 i
04 bT (Reverse feed stitching switch input)
CN50 11 i
05 LinH (Input of prohibition of depress on front part of pedal)
CN39
7 i
06 TSW (Thread trimming switch input)
11 i
07 LSSW (Low-speed revolution switch input)
9 i
08 HSSW (High-speed revolution switch input)
5 i
09 FL (Presser foot lifting switch input)
CN57 1 i1
0 CUnT (Sewing counter input)
Built-in panel
i11 noP (No function setting)
i12 noP (No function setting)
i13 noP (No function setting)
i14 noP (No function setting)
i15 noP (No function setting)
i16 noP (No function setting)
i17 noP (No function setting)
Connector No. Pin No. Display No. Initial value of function setting
CN50
7 o0
1 bT (Reverse feed stitching output)
8 o02 T
rM (Thread trimming output)
9 o03 LSW
o (Revolution request input)
* The built-in panel settings i11 to i17 are only enabled when the external panel is connected to the sewing machine.
Their numbers are not displayed when the external panel is not connected to the sewing machine.
