JUKI HZL-F series - Front panel; Rear panel

9
Connecting to the power supply
In case Start/stop button is used:
1. Turn off power switch (turn to “O”), push power cord plug into
machine receptacle.
2. Plug power plug into electric outlet.
3. Turn on power switch. (Turn to “I”.)
In case Foot controller is used:
1. Turn off power switch (turn to “O”), push power cord plug into
machine receptacle.
2. Plug power plug into electric outlet.
3. Turn on power switch. (Turn to “I”.)
* When the foot controller is used, start/stop button will:
Sewing start: will not operate
Sewing end: will operate
Power plug
Power plug
Foot controller
Plug
Controller plug socket
Machine receptacle
Warning
• When machine is not in use, turn off the power (turn to “O”) and pull out the power plug.
Otherwise, it may cause electric shock and/or re.
Power switch
Power switch
