8
Remove tape
xing the lever section of safety switch
.
1. When using the safety switch without removing tape
, it is very dangerous since the sewing
machine works even in the state that it is tillted.
2. In case error 302 occurs when the sewing machine works after setup, loosen the safety switch
tting screw with a screwdriver, and lower the switch to the downside of the sewing ma-
chine.
3-9. Safety switch
1) Fix drain receiver
in the installing hole of table
with two setscrews
.
2) Screw poly-oiler
in waste oil reservoir
.
3) Insert sewing-machine waste oil pipe
into po-
ly-oiler
.
4) Insert head support rubber
into table
.
5) Pass bundle
of cords through slotted hole
in
the table.
1. Insert drain pipe
until it will go no fur-
ther so that it does not come off drain
bin
when tilting the machine head.
2. Remove the tape xing drain pipe
.
3-8. Installing the drain receiver and the head support rubber
