20
(Caution) When using a sewing pattern which is full in lengthwise direction (+10 mm), make sure of the
clearance between cloth feed base
and wiper base
. If there is no clearance, loosen setscrew
and move the wiper
to the needle side. Especially when the needle position comes to the
rear on the right side, the clearance is decreased.
5-4. Checking the contour of a sewing pattern
Under this mode, the sewing machine
will not start running even if you depress
the pedal.
WARNING :
1. Make sure without fail of the contour of the sewing pattern after selection of the sewing pattern.
If the sewing pattern extends outside the work clamp feet, the needle will interfere with the work
clamp feet during sewing, causing dangerous troubles including needle breakage.
2. When making sure of the contour of the sewing pattern, press + / - key with the needle bar lowered,
and the work clamp feet move after automatically making the needle bar return to the upper posi-
tion.
Needle
10mm
Clearance
Clearance
1) Press READY key
to light up the SET
READY LED
.
2) Press work PRESSER and WINDER key
to display "work clamp lowering screen".
3) Display the shape check screen with + key
.
4) Check the shape with DATA CHANGE key
.
5) Press RESET key
to return to the
sewing starting position and lift the work clamp.
When you press RETURN key
, the
sewing screen is displayed at the current posi-
tion.
When you depress the pedal in the aforemen-
tioned state, the sewing machine starts sewing
from the current position.
To Next Page
