95
Install nger guard (left)
󰿿
and (right)
󱀀
on the machine head with screws
󱀁
and washers
󱀂
.
2-7. Fixing the nger guard
Put hose
󱀀
into cloth chip bag
󰿿
. Suspend the bag
from the undersurface of the table with hanger
󱀁
.
Suspend cloth chip bag
󰿿
from the lo-
cation where the top of the hose
󱀀
is
brought to the upper section of the bag.
If the hose reaches the bottom of the
cloth chip bag or the hose is clogged
with cloth chips, the suction force can be
reduced.
2-6. Installing the cloth chip bag
󰿿
󱀁
󱀀
󱀀
DANGER :
Be sure to install the nger guard since it protects ngers from contact with the mechanical section.
󱀀
󱀂
󱀁
󰿿
󱀁
󱀂
