13
Check that the place between lower line
B
and up-
per line
A
is lled with oil. Fill there with oil using the
oiler supplied with the machine as accessories when
oil is short.
* The oil tank which is lled with oil is only for lubri-
cating to the hook portion. It is possible to reduce
the oil amount when the number of rotation used
is low and the oil amount in the hook portion is
excessive. (Refer to
"I.7-8. Amount of oil sup-
plied to the hook" p.48
.)
1. Do not lubricate to the places other
than the oil tank and the hook of Cau-
tion 2 below. Trouble of components
will be caused.
2. When using the sewing machine for the
rst time or after an extended period of
disuse, use the machine after lubricat-
ing a small amount of oil to the hook
portion. (Refer to "I.7-2. Adjusting the
needle-to-shuttle relation" p.45.)
Loosen setscrew
󰿿
and hold needle
󱀀
with the long
groove
󱀁
facing toward you. Then fully insert it into
the hole in the needle bar, and tighten setscrew
󰿿
.
If the stitches are made as shown in
󱤨
,
attach the needle facing to the direction
󱤩
to a small extent.
4. OPERATION OF THE SEWING MACHINE
4-1. Lubrication
4-2. Attaching the needle
󱀀
󱀁
󱤨
󱤩
WARNING :
Turn OFF the power before starting the work so as to prevent accidents caused by abrupt start of the
sewing machine.
WARNING :
Turn OFF the power before starting the work so as to prevent accidents caused by abrupt start of the
sewing machine.
󰿿
A
B
