– 161 –
<Custom pattern edit screen>
Creating a custom pattern
1)
: Selected custom pattern number
: Step number being edited and the total
number of steps
: Display area for the created zigzag pat-
tern
: Feed amount of each step
: Stitch baseline of each step
The aforementioned ve items are displayed
o the custom pattern edit screen.
2) Set the feed amount by pressing
.
Set the stitch baseline position by pressing
.
3) When
is pressed, the needle en-
try position for step 1 is set and the screen
changes over to the step 2 setting screen.
4) Carry out the steps of procedure 2) and 3)
successively to set the needle entry position
for step 2 and beyond.
5) If you want to insert or delete a step, select
the target step by pressing
. Then,
press
or
.
6) When
is pressed, the created pattern
is repeated.
7) When
is pressed, the display
size of pattern display area
is changed
over.
To Next Page
