8-6. Condensation custom pattern
Condensation stitches can be sewn while specifying needle
entry points as desired, by setting a condensation custom.
As many as 64 stitches can be created.
As many as 20 patterns can be registered.
1. With some combinations of stitch length, di-
rection of feed and sewing speed, the sewing
machine may fail to nish a sewing pattern
exactly according to the settings.
2. Needle cannot be entered to the same needle
entry point when the stitch length is set to 0.0
mm.
3. In the case the stitch length di󰀨ers between
the normal feed and the reverse feed, correct
the stitch length appropriately with the memo-
ry switch K330 (normal direction stitch length
correction) and K331 (reverse direction stitch
length correction).
8-6-2. Creating a new condensation custom
󰴤
Selecting the condensation custom pattern setting on the mode screen
1) Press
󰿿
.
The "mode screen" is displayed.
2) Select the "5. Condensation custom sewing
setting".
The "condensation custom pattern list screen"
is displayed.
<Mode screen>
A new condensation custom pattern creation procedure is described as follows using <Figure: Example of
the condensation custom> as an example.
8-6-1. Selecting the condensation custom
Select condensation custom pattern referring to
"5-2-3. (2)

In the case of maintenance personnel mode" p.
49
.
The condensation custom pattern for reverse-feed stitching at the end of sewing can be set in the similar
manner.
<Figure: Example of the
condensation custom>
Condensation
custom
󰿿
