– 47 –
Name Function
Pattern No. button This button is used for displaying numbers of the registered sewing patterns and cycle
patterns.
(Cycle pattern numbers that are not registered are not displayed.)
When this button is pressed, the sewing pattern is put into the selected state.
Display range: Sewing pattern numbers 1 to 200 and cycle patterns 1 to 20.
Pattern number (in the
order of registration of
characters) button
Sewing pattern is displayed and the pattern is put into the selected state by pressing this
button.
Sorting button This button is used for sorting the registered patterns in the order of sewing pattern
number, process, part number or comment.
Pattern No. display range: Sewing pattern numbers 1 to 200 and cycle patterns 1 to 20.
Registration of characters display range: Sewing pattern numbers 1 to 200.
Rening button This button is used for displaying the rener setting screen.
New sewing pattern
creation button
This button is used for creating a new sewing pattern.
Refer to
"8-1-1. Creation of a new pattern" p. 137
.
* This button is only displayed under the maintenance personnel mode.
New cycle pattern creation
button
This button is used for creating a new cycle pattern.
Refer to
"8-4. Cycle pattern" p. 153
.
* This button is only displayed under the maintenance personnel mode.
Pattern copy button This button is used for copying a sewing pattern or cycle pattern and registering the
copied pattern with new number.
Refer to
"8-1-2. Copying a pattern" p. 139
.
* This button is only displayed under the maintenance personnel mode.
Pattern delete button This button is used for displaying the pattern deletion conrmation message.
In the case there is only one registered pattern, the pattern cannot be deleted.
* This button is only displayed under the maintenance personnel mode.
Scroll (up) button This button is used for displaying the previous page.
Scroll (down) button This button is used for displaying the next page.
Close button This button is used for cancelling the selected pattern and displaying the sewing screen.
Enter button This button is used for conrming the selected pattern and displaying the sewing screen.
Display of pattern data
being selected
This button is used for displaying data on the pattern that is being selected.
To Next Page
