– 70 –
(3) Setting items for steps of a continuous sewing pattern
Data No. Item name
Unit of
change
Input range
Step 01
S611 Sewing shape ― Refer to S002
S612 Number of stitches 1 stitch
1 to 2000
S613 Zigzag width 0.1 mm Refer to S072
S614 Stitch length 0.1 mm
-5.0 to 5.0
S615 Reverse feed stitch length 0.1 mm
-5.0 to 5.0
S616 Start position of scallop stitch ―
: Bottom of crescent scallop
: Apex of crescent scallop
S617 Stop position of scallop stitch ―
: Optional
: Bottom of crescent scallop
S618 Number of blind stitches 1 stitch
3 to 250
S619 Sewing starting position ― Refer to S077
S620 Sewing end position ― Refer to S078
S625 Stitch length 2 0.1 mm
-5.0 to 5.0
Step 02
・
・
Step 20
* Setting items and the input range are same as those of step 01.
* Step numbers can be set to Step 20.
To Next Page
