Control and function elements
11
Mains connection: Integrated connector for voltage supply (mains cable included
as accessory)
12 Fuses: Miniature circuit-breaker
13 CAN plug for connecting to the refrigeration machine.
14 USB device interface (type B) for data transfer to the PC, for example for control tasks
using the EasyTEMP software.
15 Pump connection: Return, IN M16x1, external
16 Pump connection: Supply, OUT M16x1, external
Refrigerated Circulators
17 Recessed handle (front, rear)
18 CAN connection cable for refrigeration machine circulator
19 CAN plug for connecting to the circulator.
20 Fuses: Miniature circuit-breakers, for refrigeration machine
Resettable fuses for 600F refrigeration units (115 V, 100 V)
