The circulator is used for temperature application to
external, closed systems (loop circuit) with
simultaneous temperature application in the
circulator bath.
Connecting the external system
• Unscrew the collar nuts from the pump connector
(24a).
• Slide the tubing onto the pump connectors for
feed and return flow (24a, 24b).
Tubing and insulation for tubing see page 21
Caution: Securely attach all tubing to prevent slipping.
