12.3. List of commands
out commands: Setting temperature values or parameters.
Command Parameter Response of circulator
out_mode_01 0
Use working temperature > SETPNT 1<
out_mode_01 1
Use working temperature > SETPNT 2<
out_mode_01 2
Use working temperature > SETPNT 3<
out_mode_04 0 Temperature control of internal bath.
out_mode_04 1 External control with Pt100 sensor.
out_mode_05 0 Stop the unit = R –OFF-.
out_mode_05 1 Start the unit.
out_mode_08 0 Set the control dynamics - aperiodic
out_mode_08 1 Set the control dynamics - standard
out_sp_00 xxx.xx Set working temperature. „SETPNT 1“
out_sp_01 xxx.xx Set working temperature. „SETPNT 2“
out_sp_02 xxx.xx Set working temperature. „SETPNT 3“
out_sp_03 xxx.xx
Set high temperature warning limit „OVERTMP“
out_sp_04 xxx.xx
Set low temperature warning limit „SUBTMP“
out_sp_07 x Set the pump pressure stage. (1 ... 4)
out_par_04 x.x CoSpeed 0 ... 5.0 Band limit during external control.
Setting the maximum difference between the temperatures
in the internal bath and external system.
out_par_06 xxx Xp control parameter of the internal controller. 0.1 ... 99.9
out_par_07 xxx Tn control parameter of the internal controller. 3 ... 9999
out_par_08 xxx Tv control parameter of the internal controller. 0 ... 999
out_par_09 xxx Xp control parameter of the cascade controller. 0.1 ... 99.9
out_par_10 xxx Proportional portion of the cascade controller. 1 ... 99.9
out_par_11 xxx Tn control parameter of the cascade controller. 3 ... 9999
out_par_12 xxx Tv control parameter of the cascade controller. 0 ... 999
out_par_13 xxx Maximum internal temperature of the cascade controller.
out_par_14 xxx Minimum internal temperature of the cascade controller.
out_par_15 xxx
Band limit (upper) 0 ... 200 °C
out_par_16 xxx
Band limit (lower) 0 ... 200 °C
