4 Operation
4.5 Entries and operator prompting
Entering values
When entries are made within the levels, the parameter symbol
appears in the lower display.
1. Select parameter by pressing or
2. Change to the entry mode using
(lower display blinks)
3. Change a value using and
The value alters dynamically for as long as the key is kept pressed.
4. Take over the entry with
or automatic return after 2s
or cancel the entry with
The value will not be applied.
TIP!
If the function key is pressed for > 2s, the device
changes back to normal display.
P
P
Change value
(top - red)
Parameter flashes
Select parameter
(bottom - green)
