2 Installation
2.1 Installation site and ambient
conditions
The ambient conditions at the installation site must meet the
requirements specified in the technical data.
Ö Chapter 8.1 „Technical Data“
The device is not suitable for use in areas with an explosion hazard (Ex
areas).
Cleaning the device front
The device front can be cleaned using warm or hot water (possibly
adding slightly acidic, neutral or slightly alkaline cleaning agent). It has
a limited resistance to organic solvents (e. g. methylated spirits, white
spirit, etc .). Do not use abrasive or high-pressure cleaning equipment.
2.2 Dimensions
Close mounting
Minimum spacing of panel cut-outs
Type horizontal vertical
without setup plug:
702071 (48mm x 48mm)
702072 (48mm x 96mm)
702074 (96mm x 96mm)
> 8mm
> 10mm
> 10mm
> 8mm
> 10mm
> 10mm
with setup plug:
702071 (48mm x 48mm)
702072 (48mm x 96mm)
702074 (96mm x 96mm)
> 8mm
> 10mm
> 10mm
> 65mm
> 10mm
> 10mm
