49
7 Configuration level
7.6 Outputs
The configuration of the device outputs is subdivided in binary outputs
(OutL) and analog outputs (OutA). Binary outputs are relays and logic
outputs. The switching states of the binary outputs 1 to 4 are shown
in the display (K1 to K4).
Binary outputs
Output 1 (Out1) = Relay
Output 2 (Out2) = Relay
Output 3 (Out3) = Logic output
Output 4 (Out4) = Relay (option)
ConF -> OutP-> OutL ->
Parameters Value/
Selection
Description
Binary outputs
0ut1
0ut2
0ut3
0ut4
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
no function
Controller output 1 (factory-set to Out1)
(e.g.„Heating“, with inverse control direction)
Controller output 2 (e.g. „Cooling“, see above)
Binary input 1
Binary input 2
Limit comparator 1
Limit comparator 2
Timer signal
Timer runs
Timer completed
Timer waiting
(reserved)
(reserved)
Tolerance band signal, ramp
Ramp end signal
Service alarm
(reserved)
Actuation of F key
Manual mode
