7 Configuration level
50
Analog output
The device can optionally be equipped with an analog output.
ConF -> OutP-> OutA ->
Parameters Value/
Selection
Description
Function
FnCt
(Analog
selector)
Controller
output
value
Function of the output
Type of signal
S iGn
0
1
2
3
0...10V
2...10V
0...20mA
4...20mA
Physical output signal
Value at Out of
Range
r0ut
0…101 Signal (in percent) at overrange or
underrange
101=last output signal
Zero point
0Pnt
-1999…
0…
+9999
A value range of the output variable is
assigned to a physical output signal.
The ex-factory setting corresponds to an
output value of 0...100% for controller
outputs.
No changes of the ex-factory setting are
required for continuous controllers.
For a 3-state controller, enter the
following settings for cooling:
Zero point = 0 / End value = -100
Example (function as a transducer):
The analog output (0...20mA) is to be used
to put out the process value (value range:
150...500°C), this means:
150…500°C = 0…20mA
Zero point: 150 / End value: 500
End value
End
-1999…
100…
+9999
