7 Configuration level
58
7.9 Interface
The device can be integrated into a data network (Modbus) via an
optional RS485 interface.
ConF -> IntF ->
Parameters Value/
Selection
Description
Baud rate
bdrt
0
1
2
9600 bps
19200 bps
38400 bps
Data
format
dFt
0
1
2
3
8 data bits, 1 stop bit, no parity
8 data bits, 1 stop bit, odd parity
8 data bits, 1 stop bit, even parity
8 data bits, 2 stop bits, no parity
Device address
Adr
0…1…
255
Address in data network
Min. response
time
(Setup)
0…
500ms
Time period in milli-seconds that elapses
between the request of a device in the data
network and the response of the controller.
Setting in the setup program
(-> Interface)
TIP!
When the communication takes place via the setup
interface, the RS485 interface is inactive.
TIP!
For further information a separate interface description
Modbus (B70.2070.2.0) is available as a PDF file (on the
mini-CD or via internet).
