8.1 Technical Data
Thermocouple input
RTD temperature probe input
Designation Measuring
range
1
1
The specifications refer to an ambient temperature of 20°C.
Measuring
accuracy
2
2
Incl. measuring accuracy at the cold junction. The accuracy values refer to
the maximum measuring range. Small measuring ranges lead to reduced
linearisation accuracy.
Ambient
temperature
coefficient
EN
Fe-CuNi „L“
Fe-CuNi „J“
Cu-CuNi „U“
Cu-CuNi „T“
NiCr-Ni „K“
NiCr-CuNi „E“
NiCrSi-NiSi „N“
Pt10Rh-Pt „S“
Pt13Rh-Pt „R“
Pt30Rh-Pt6Rh „B“
W5Re-W26Re „C“
W3Re-W25Re „D“
W3Re-W26Re
60584
60584
60584
60584
60584
60584
60584
60584
-200… +900°C
-200…+1200°C
-200… +600°C
-200… +400°C
-200…+1372°C
-200… +900°C
-100…+1300°C
0… +1768°C
0… +1768°C
0… +1820°C
0… +2320°C
0… +2495°C
0… +2400°C
≤ 0.25%
≤ 0.25%
≤ 0.25%
≤ 0.25%
≤ 0.25%
≤ 0.25%
≤ 0.25%
≤ 0.25%
≤ 0.25%
≤ 0.25%
3
≤ 0.25%
≤ 0.25%
≤ 0.25%
3
In the range of 300...1820°C
100ppm/K
100ppm/K
100ppm/K
100ppm/K
100ppm/K
100ppm/K
100ppm/K
100ppm/K
100ppm/K
100ppm/K
100ppm/K
100ppm/K
100ppm/K
Cold junction: Pt100 internal
Designation,
Connection type
Measuring
range
Measuring
accuracy
1
Ambient
temperature
coefficient
Pt100 EN 60751
2 wire connection
3 wire connection
-200…+850°C
≤ 0.4%
≤ 0.1%
50ppm/K
To Next Page
