8 Supplement
60
Standard signals input
Binary inputs
Pt1000 EN 60751
2 wire connection
3 wire connection
-200…+850°C
≤ 0.2%
≤ 0.1%
50ppm/K
KTY11-6
2 wire connection
-50…+150°C
≤ 2.0%
50ppm/K
Sensor lead resistance: max. 30Ω per lead with three wire circuit
Measuring current: approx. 250µA
Lead compensation: Not required for three wire circuit. For a 2-wire circuit,
the lead resistance can be compensated by correcting the actual value.
1
The accuracy values refer to the maximum measuring range. Small
measuring ranges lead to reduced linearisation accuracy.
Measuring range Measuring
accuracy
1
1
The accuracy values refer to the maximum measuring range. Small
measuring ranges lead to reduced linearisation accuracy.
Ambient
temperature
coefficient
Voltage 0(2)…10V
Input resistance R
E
> 100kΩ
≤ 0.1% 100ppm/K
Current 0(4)…20mA
Voltage drop ≤ 2.2V
≤ 0.1% 100ppm/K
Potential-free contact open = inactive;
closed = active
Designation,
Connection type
Measuring
range
Measuring
accuracy
1
Ambient
temperature
coefficient
