57
7 Configuration level
Signal to be
monitored
(Setup)
Controller
output 1
Selection of the binary signal to be
monitored
Setting in the setup program
(-> Display/Operation/Service counter ->
Service counter):
- deactivated
- Controller output 1
- Controller output 2
- Binary input 1
- Binary input 2
- Limit comparator 1
- Limit comparator 2
- Timer signal
- Timer runs
- Timer completed
- Timer waiting
- Tolerance band signal
- Ramp end
- Service alarm
- Key actuation
- Manual mode
User level
(Setup)
A maximum of eight parameters from the
various levels can be defined to be
available in the user level of the device. The
parameter name (max. 4 characters which
can be displayed with 7-segment display)
can be user-defined. Without a user-default
entry, the name programmed in the device
will appear.
Setting in the setup program
(-> Display/Operation/Service counter ->
User level)
Parameters Value/
Selection
Description
