47
7 Configuration level
ConF -> tFCt ->
Parameters Value/
Selection
Description
Function
FnCt
0
1
2
no function
Timer
Timer for time-delayed control
Start condition
Strt
0
1
2
Timer is manually started using the
function key or the binary signal.
Manual (see above) and automatic start
after power ON. Restart after power failure.
Manual (see above) and automatic start
after power ON. Continued run after power
failure.
(Residual running time is saved every
minute.)
Time unit
Unit
0
1
2
mm.ss
hh.mm
hhh.h
Timer signal
SiGn
0
1
inverted
not inverted
Set time t1
t1
(Timer time)
00.00.
…
99.99.
The started timer runs for this time in the
specified time unit.
Set time t2
t2
(Timer follow-up
time)
-1…
0…
+9999
This time (in seconds) can be used to
transmit a time limited or acknowledgeable
signal after the timer time has elapsed.
0 = switched off
1…9999 = active for the set time
-1 = active until acknowledged
Acknowledgement:
For t2 = -1 the timer follow-up time is
infinite. Cancel the signal using a function
key or the binary signal.
