1 Introduction
10
1.5 Identifying the device version
1.5.1 Nameplate
The nameplate is affixed to the housing.
Contents
The nameplate contains important information. This includes:
Device type (Typ)
Compare the specifications on the nameplate with the order.
Identify the supplied device version using the order details (order code).
Part no. (TN)
The part no. uniquely identifies an article in the catalog. It is important for communication between the
customer and the sales department.
Serial number (F-Nr.)
The serial number indicates, among other things, the date of manufacture (year/week).
Example: F-no. = 0070033801217480006
The characters in question are digits 12, 13, 14, and 15 (from the left).
Thus the device was produced in calendar week 48 of 2017.
Description Designation on the
nameplate
Example
Device type Typ 702114/81-4356-25/214
Part no. TN 00123456
Serial number F-Nr. 0070033801217480006
Voltage supply - AC/DC 20 to 30 V, 48 to 63 Hz
