JUMO diraTRON Series User Manual

81
8 Configuration - setup only
NOTE!
The trigonometric functions (SIN, COS, and TAN operators) use degrees (360).
Behavior after power on
All calculations are restarted after power on. The output values are set to 0.
8.6 Service
A service counter can be implemented with this function. The switch-on duration or the switching fre-
quency of a binary signal is counted here. The service signal is activated once the limit value is reached
and remains active until acknowledgement.
In addition, an operating hours counter is available that determines the device's operation duration.
Decimal places Decimal places for the numerical display of the val-
ue
Auto Automatic
XXXX. No decimal place
XXX.X One decimal place
XX.XX Two decimal places
X.XXX Three decimal places
Response in case of a
fault
Value of the output signal in the event of a fault
(e.g., in case of overrange or underrange)
Output error value The math error value 5.0E+37 is output (display: -
---).
Output replacement val-
ue
The replacement value is output (see "Replace-
ment value in the event of a fault" parameter).
Replacement value in
the event of a fault
-1999 to 9999 (0) Replacement value for output in the event of a fault
Additional functions Parameter 1
parameter 2
Parameter 1: Monitoring of the limits of the display
range. If the math result is outside of the limits, this
is considered as a deviation above or below the
measuring range.
Parameter 2: Reserved function for service pur-
poses. Only activate when instructed to do so by
service personnel!
Click checkbox to activate the function.
Parameter Selection/text/value Description
Parameter Selection/text/value Description
Service interval 0 to 10000000 Limit value (number or time in hours or minutes)
Function Number of switch op-
erations
Counts the switching frequency of a binary signal.
Time in hours Counts the switch-on duration of a binary signal in
hours.
Time in days Counts the switch-on duration of a binary signal in
days.
Signal to be monitored Digital selector
No selection
Binary signal whose switching frequency or
switch-on duration is counted.
Acknowledgement sig-
nal
Digital selector
No selection
Binary signal (high active) to acknowledge the ser-
vice signal
