7 Configuration
7 Confi guration
This chapter describes the configuration based on the menu items and parameters of the device: MENU
> CONFIGURATION
The description also applies for the configuration with the setup program (identification, configuration
level).
Functions and parameters that only exist on the device or in the setup program are marked as "(device
only)" or "(setup only)".
Beyond this, there are additional functions that can only be configured or executed with the setup pro-
gram. These functions are described in separate chapters:
chapter 8 "Configuration - setup only", page 77
chapter 9 "Online parameter (setup only)", page 85
chapter 10 "Start-up parameter (setup only)", page 91
The default settings are shown in bold in the tables.
NOTE!
No separate voltage supply is required for configuring using the setup program as the device is supplied
via the USB interface (USB-powered). For a device in format 104, in this case the outputs are deactivat-
ed.
7.1 Identification (setup only)
Hardware assistant
The device version is specified in this menu:
Device type
Optional inputs and outputs as well as RS485 interface
Math/logic extra codes and ST code
The following options are available for this purpose:
User setting: The device version is selected by the user in the setup program.
Automatic detection: The device version is read out from the connected device and transferred to
the setup program.
Automatic detection with read out of setup file: The configuration is additionally read out from the de-
vice here and transferred to the setup program.
Connection diagram
The user can use this function to create a connection diagram that shows the current terminal assign-
ment of the device.
There are some text entry fields that can be used for the description at the bottom edge of the connection
diagram. Alternatively, the texts from the file info header of the setup file can also be used here (setting
in the context menu, see below). There is also one field for the date (editable) and one for the signature.
There is a print function, incl. print preview and printer selection, available via the context menu (mouse
pointer in the connection diagram, right mouse button). The features for the protocol to be printed are
also defined here (page margins, line type, use of texts from the file info header).
7.2 Selectors
The selectors contain signals that are available for configuration on the device or in the setup program.
These are device signals (e.g., analog and digital inputs or internal signals), and signals that are trans-
ferred to the device via Modbus (external analog and digital inputs, analog and digital flags).
