2 Mounting
16
2.3 Dimensions
Type 702110 (format 132: 48 mm × 24 mm)
Type 702111 (format 116: 48 mm × 48 mm)
3.8
26.5
89
22
25.4
44.5
48
49.4
24
48
4.8
77.9
50
44.5
48
48
48
44.5
