7 Configuration
Parameter Selection/text/value Description
Signal type No sensor No sensor selected
2L RTD temperature
probe
RTD temperature probe in two-wire circuit
3L RTD temperature
probe
RTD temperature probe in three-wire circuit
2L resistance/potenti-
ometer
Resistance/potentiometer in two-wire circuit
3L resistance/potenti-
ometer
Resistance/potentiometer in three-wire circuit
Resistance transmitter Resistance transmitter
Thermocouple Thermocouple
0...10 V Voltage signal
2...10 V Voltage signal
0...20 mA Current signal
4...20 mA Current signal
Linearization Pt100 Only with RTD temperature probe
GOST Pt100
Pt1000
KTY two-wire
L / Fe_CuNi Only with thermocouple
J / Fe_CuNi
U / Cu-CuNi
T / Cu-CuNi
K / NiCr-Ni
E / NiCr-CuNi
N / NiCrSi-NiSi
S / Pt10Rh-Pt
R / Pt13Rh-Pt
B / Pt30Rh-Pt6Rh
C / W5Re-W26Re
D / W3Re-W25Re
A1 / W5Re-W20Re
L / Chromel®-Copel®
Chromel®-Alumel®
Linear Only with resistance/potentiometer, resistance
transmitter, voltage, current
Customer-specific Customer-specific linearization with 4th order poly-
nomial or grid points (configurable with setup pro-
gram)
Temperature Only with resistance/potentiometer, resistance
transmitter, voltage, current:
This selection is important for the automatic con-
version in case of a change in temperature unit
(°C/°F) (see system data).
None The value is not a temperature.
Relative The value is a temperature difference.
Absolute The value is a temperature value.
