7 Configuration
70
Behavior after power on
(setup only)
Abort Timer aborted
Continuation Timer continues to run for the remaining running
time.
Any minute of remaining running time that is not
completed is repeated; examples (mm:ss):
power off at 09:01, continuation at 10:00
power off at 09:00, continuation at 09:00
Restart Timer restarts at the timer time.
The lead time is not considered in case of a restart.
Time display Timer time unit (for input and display on the device)
mm:ss Minutes:Seconds
hh:mm Hours:Minutes
dd:hh Days:Hours
Timer time Time after timer start
The setting range depends on the configured time
unit:
00:00 to 59:59 mm:ss
00:00 to 23:59 hh:mm
00:00 to 99:23 dd:hh
Lead time 0 to 9999 Time before timer start (in seconds)
After-run time -1 to 9999 (0) Time after timer end (in seconds)
-1 = active until acknowledged
The end signal is active during the after-run time.
Acknowledgement sig-
nal
Digital selector
No selection
Only if after-run time ≠ 0: signal (active for rising
edge) to acknowledge the end signal
Start signal Digital selector
No selection
Signal (active for rising edge) to start the timer
The start signal only works while the timer is not
running or during the after-run time (not during the
lead time or runtime).
Abort signal Digital selector
No selection
Signal (active for rising edge) to abort the timer
The abort signal only works during the runtime (not
during the lead time or after-run time).
Stop signal Digital selector
No selection
Signal (high active) for stopping the timer
The stop signal only works during the lead time
and runtime (not during the after-run time).
Restart signal Digital selector
No selection
Signal (active for rising edge) to reset and restart
the timer
The restart signal only works during the runtime
(not during the lead time or after-run time); it can-
not be used to start the timer.
The lead time is not considered in case of a restart.
Output signal High active Output signal: high active while timer is running
Low active Output signal: low active while timer is running
