1 Introduction
12
1.3.2 Order details
(1) Basic type
706520 Paperless recorder with 1x Ethernet, 2x USB (1x host, 1x device), and 1x RS232/485
interface and one relay
(2) Basic type extension
0 Without software package
1 With software package (setup program incl. USB cable, PC Evaluation Software
PCA3000, PCA Communication Software PCC; in conjunction with extra code „888“:
additionally with software PC Security Manager PCS and PC Audit-Trail Manager
PCAT)
(3) Language
8 Set per default (German/English)
9 Set according to customer specifications
(4) Option 1 (expansion slot 1)
1
1
Subsequent expansion is only possible in JUMO Central Services.
0 Not used
1 3 analog and 6 digital inputs, 1 analog output
(5) Option 2 (expansion slot 2)
a
0 Not used
1 3 analog and 6 digital inputs, 1 analog output
(6) Option 3 (expansion slot 3)
a
0 Not used
1 12 digital inputs/outputs (independently configurable as input or output)
(7) Voltage supply
23 AC 110 to 240 V +10/-15 %, 48 to 63 Hz
25 AC/DC 20 to 30 V, 48 to 63 Hz
(8) Extra code
. Not used
260 Math and logic module (6 channels each)
(9) Extra code
. Not used
887 Manipulation detection with digital certificate
888 FDA 21 CFR Part 11 with digital certificate
(10) Extra code case
. Not used
970 Universal carrying case Compact
2
2
This extra code is only available in combination with voltage supply AC 110 to 240 V. The UL approval
is not applicable. Use only by technically qualified personnel who are specially trained and have the
relevant knowledge in the field of automation technology! Observe the ambient temperature and the
protection type (see technical data)!
