5 Operation
38
5.3.2 Event list
The event list contains event entries in chronological order. A maximum of 150 entries are
stored and displayed. When new entries are added, the oldest entries are deleted. The event
list is kept after power off.
As with process data, events are transferred to the PC Evaluation Software PCA3000 for eval-
uation.
Events include:
• System messages ( e.g., power on, configuration change, time sync)
• Device alarms (malfunctions; e.g., battery discharged, data loss, input not calibrated)
• Configured alarms
• Configured events
• Counter messages (counter status and counter reset)
• Batch messages (start and end of batch recording)
• General messages (e.g., comments, error messages from the interfaces, USB flash drive
plugged in/removed, collective alarm acknowledged)
View
(1) Event (here: alarm) with time and event
text (configurable)
(3) Update event list
(2) Quit event list
