5 Operation
50
Detailed view
(1) Description (pointer) and short analog
signal description (configurable); report
type (configurable; here: external)
(4) Completed report
(2) Time at which the max. value (or min.
value) occurred
(5) Current (on-going) report
(3) Time stamp for current report: beginning
of recording and current time
Time stamp for completed report: begin-
ning and end of reporting period
(6) Back to previous view
