Menu structure of the paperless recorder
v Chapter 8 "Device Manager"
v Chapter 7 "Memory Manager"
v Chapter 6 "Alarm and Event Lists"
v Chapter 4 "Visualization"
v Chapter 5 "Memory Presentation (History)"
New device functions
The device software version 187.03.xx is replaced by version 187.04.xx. The following ad-
ditional functions are available with the new version:
-additional horizontal recorder image; applicable for curve presentation, for binary pre-
sentation, for display of a closed batch, and for memory presentation
-Expansion of the external inputs from 24 to 54
-Expansion of the external texts from 9 to 27
-Time synchronization through SNTP
-New web server
-Modbus slave monitoring (timeout monitoring)
The device software can be checked in the menu Device manager
Î Device info Î Ver-
sion
Î SW version.
